Marinco ConnectPRO 12V Charging & Trolling Receptacle and Plug Set – Model 12VCP

Description

ConnectPro® Charging/Trolling System Receptacle & Plug
ConnectPro® Receptacle

• Universal design for 2 or 3-wire configuration 12, 24, 12/24, 24/36 or 36 volt systems
• Watertight sealing cap
• Corrosion resistant, plated brass electrical components
• Drain holes in receptacle keep water away from electrical components
• Perma-Lock™ screw terminals will not loosen under extreme hull vibration
• Standard 1-1/8″ diameter mounting hole
• Easy to install, with supplied mounting plate for front panel installation, or locking ring for rear access installation
• Accepts 10 and 8 gauge wire
• Easily replaces other trolling motor plugs and receptacles

ConnectPro® Plug

• O-ring seal for waterproof connections
• Weather resistant plug cover
• Corrosion resistant, plated brass electrical components
• Accepts 16 to 8 gauge wire
• Ergonomic contoured grip for easy hook-up and ground blade alignment

WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov.

Specifications:

• Type: Misc
• Box Dimensions: 2″H x 5″W x 9″L WT: 0.35 lbs
• UPC: 093344304668

Brochure (pdf)
