Ronstan RF20100 Series 20 Single Ball Bearing Block

Description

Series 20 Ball Bearing Block – Single
Features:

• Low friction
• High static and dynamic load capacity
• Lightweight
• Precision molded Acetal sheaves running on stainless steel or Torlon® ball bearings provide high performance & low friction

Applications:

• Dinghy control lines
• Dinghy Vangs
• Cunninghams
• Traveller controls

Materials:

• U.V. Stabilized Acetal sheaves
• Stainless steel ball bearings
• Grade 316 stainless steel load strap and head fitting
• Impact and UV resistant, fiber reinforced Nylon cheeks

Specifications:
Sheave Ø: 20mm(3/4″)
Max. Rope Ø: 6mm(1/4″)
Pin Ø: 3mm(1/8″)
M.W.L.: 250kg(550lbs)
B. L.: 550kg(1,210lbs)
Weight: 20g(0.7oz)
